Description
NOTE: Refurbished printers have been cleaned and serviced by certified LogoJET technicians, however cosmetic wear, scuffs and ink staining may be visible from previous use.
LogoJET's UVx90R incorporates six Ricoh GH2220 print heads to achieve our fastest print speeds ever! Each print head has 2 ink channels (for a total of 12) to allow for maximum ink output, thus reducing the print passes needed to achieve high-quality, vibrant imprints. There are 2 channels assigned to each of the four CMYK color inks, leaving the last 4 channels customizable with any combination of White ink, Primer or Clear Gloss. This allows you to print on an endless variety of substrates including dark and clear materials, as well as the capability to build textures, underlays and overlays for special effects.
LogoJET's UVx90R has a print area of 24”L x 36”W x 6”H. The adjustable flatbed has a built-in vacuum for holding flat, lightweight substrates in place. Easily repositionable tray fixtures are also available, making it easy to print on virtually any object made of metal, plastic, rubber, glass, ceramic, stone and more!
Click here for PDF brochure.
This refurbished UVx90R Printer will include:
FEATURES:
Each printer is shipped with the following:
Features
6 RICOH GH 2220 PRECISION PRINT HEADS FOR MAXIMUM PRINT SPEED
- Newly configured ink system contains 6 customizable channels
- Curable imprint area of 24 x 36 inches with 6 inch height clearance
- New location of ink basket creates a self-agitating ink system
- Built-in vacuum bed holds flat, lightweight substrates in place
- Control panel puts all functions at your finger-tips including:
- perform head-cleanings and nozzle checks
- manual and automatic flatbed height adjustment
- move bed backward and forward
- Acrylic cover lifts easily providing access for maintenance and ink replacement.
- Flatbed is open at the back and front, allowing oversized products to be loaded and products in trays can be accessed during print runs for continuous loading and unloading (max. product width: 25.125").
- Metal printer stand included.
- Printer measures approx. 56.25" W x 61" L x 29.5" H; Weighs approx. 410 lbs.
- Shipping weight approx. 740 lbs
Ink Capabilities
The UVx90R uses SIX RICOH GH 2220 print heads allowing it to print high quality images at much faster speeds. The standard CMYK inks are assigned to four of the print heads, leaving the last two customizable with any combination of white ink and/or clear gloss to suit your specific needs.
Ink System
The new location of our ink bags allows them to ride along during the printing process — contributing to a self-agitating system — effectively reducing setup time and simplifying the start-up procedure. Each 200 mL vacuum-sealed ink bag is designed to operate as a bulk ink solution, while keeping a closed ink system. Without interrupting the flow, simply remove the ink needle from an empty bag and insert it into a new one.
White Ink
White ink allows you to print directly onto dark and clear materials. You can print solid white imprints, or use it as an opaque base for color imprints. It can also be printed as a gradient under photographs, giving you white highlights where you need them.
Clear Gloss
The clear gloss can be printed as a spot varnish on specific areas of a design to create special effects or embellishments. It gives a high-end look when printed alone on a matte black or dark-colored background. It can also be used as a full coverage glossy clear coat to provide added durability and protection.
Production Features
LogoJET’s UVx90R has been tailored for industrial applications with maximum output efficiency. Built with high-end industrial-strength components, such as kevlar belts and strong Servo motors, you can expect a tough, reliable printer that’s designed to last.
This new configuration incorporates SIX RICOH GH print heads for our fastest print speeds ever with excellent cost performance.
The UVx90R has an imprint area of 24”W x 36”L x 6”H. The automatic height sensor detects products and positions them at an optimum distance (2mm) from the print head. Our interchangeable printing trays make it easy to print on all types of product and increase efficiency for larger production volumes. A built-in vacuum bed holds lightweight products in place on the flatbed during printing, or use our adhesive multi-use mat for securing heavier products or printing templates for custom-shaped products. The built-in UV-LED lamp cures the ink instantly as it’s applied to the substrate for vibrant and lasting imprints on metal, glass, wood, stone, plastic, fabric, vinyl and MUCH more.
Award Winning RIP Software
LogoJET Print Pro RIP software, powered by Kothari, is one of the most powerful and versatile RIP software products available (Click here for brochure). Version 7 of Print Pro is now available for all R-Series printers and includes advanced features such as:
Workflow and Automation
- Hot folders to automate workflow
- Templating and template management for replicable jobs
- Full customization of user environments
- Job queuing and prioritization
- Run multiple jobs and work on multiple art files simultaneously
- Variable data and data merge options also available
Art and Sampling
- Edit and adjust artwork from directly within the RIP
- Save multiple versions and create templates
Color Management
- Industry-leading color profiling
- Spot color replacement
- Control dot size to improve imprints on variable surfaces
Special Printing Features
- Inline one-pass printing, regardless of the number of layers
- Job costing – track ink cost and time metrics
- Automatically generate white and clear layers with a single art file
LogoJET also offers customized ICC color profiling to improve the accuracy and consistency of color imprints from one substrate to another.

Tech Support
LogoJET offers enhanced remote installation and training with all UVx90R printer purchases. LogoJET offers a one-year warranty on our REFURBISHED UVx90R printer to give you peace of mind. We pride ourselves on our top notch technical support via telephone, email, live chat and skype video so you can reach us any time you have a question or run into difficulty.
Each printer is shipped with the following:
- 1 x Metal Printer Stand
- 1 x INK BAG SET 6 colors, 200mL each (customer's choice of configuration)
- 1 x bag of gloves and maintenance syringes
- 1 x mini supply of lubricants for greasing the rails and tracks
- 1 x mini supply of cleaning solution for printer
- 1 x bag of lint free wipes
- 1 x Printed Manual
- 1 x installation USB for drivers and other videos
- 1 x Print Pro Kothari RIP software (billed separately)
- 1 x Anti Static Brush
- 1 x Power Cable
- 1 x Spare dampers set
- Built-in LCD Panel display with touch-button controls
- 1 Year Warranty
